Features:
Constant current mode
Output SELV protection, short circiut, over current and over voltage protection
Extremely high precision current；
Dimming range: 3%-100%
High power factor
Dimming mode: stepless adjusted or single adjusted
Standards:
TUV EN60950-1 EN61347-2-13 EN55015 EN55022(CISPR22) EN61000-3-2
EN61000-3-3 EN61000-4-2 ENV50204 EN55024
Specification：
| Models | Input Voltage (V) | P.F. | Output Voltage (V) | Output Current(mA) | Output Power (W) | Dimension L*W*H(mm) |
| SIAH62065BF3 | 220-240Vac | 0.95 | 46-62V | 650mA | 30-40W | 125.5*76.5*33.2 |
| SIAH57070BF3 | 42-57V | 700mA | ||||
| ... | ... | ... | ||||
| SIAH27A15BF3 | 20-27V | 1500mA |
P.S.: The current step is 50mA, contact us for the specs out of above tables.
Application：
