Description:
Specification:
| Model | HK-260 |
| Distance between centers | 550mm |
| Swing over bed | 260mm |
| Swing over cross slide | 150mm |
| Width of bed | 145mm |
| Taper of spindle | MT3 |
| Spindle bore | 26mm |
| Chuck diameter | 125mm |
| Spindle speed | 80-1600rpm，12 class（80/108/140/180/236/315/410/550/710/925/1225/1600) |
| Longitudinal feed | 0.1-0.18mm |
| Imperial thread | 8-56TPI |
| Metric thread | 0.2-3.5mm |
| Top slide travel | 50mm |
| Cross slide travel | 140mm |
| Tailstock quill travel | 60mm |
| Taper of tailstock quill | MT2 |
| Motor power | 750W |
| Packing size (L*W*H) | 1200*760*600mm |
| N.W./G.W. | 140kg/160kg |
