Description:
| Model | HK-210X Vario |
| Lathe | |
| Dsitance between centers | 400mm |
| Swing over bed | 210mm |
| Spindle taper | MT3 |
| Spindle through hole | 21mm |
| Spindle speed | 50-2500rpm |
| Longitudinal feeds | 0.08-0.16mm |
| Imperial threads | 10-44 T.P.I. |
| Metric threads | 0.5-3mm |
| Top slide travel | 55mm |
| Cross slide travel | 75mm |
| Tailstock quill travel | 65mm |
| Taper of tailstock quill | MT2 |
| Motor power | 600W |
| Packing size (L*W*H) | 910*480*850mm |
| N.W./G.W. | 120kg/150kg |
| Mill head | |
| Spindle taper | MT2 |
| Spindle speed | 50-2500rpm |
| Head rotation | ±45° |
| Max distance between work table and spindle | 260mm |
| Max distance betwenn spindle and column | 260mm |
| Motor of mill head | 600W |
