DMK50/DMK50A端面数控车床

产品型号:DMK50/DMK50A

产品品牌:SINOBASE

最小起订量:1

原产地:中国

Email 点击询价


End Face CNC Lathe _ DMK50/DMK50A



Main features:

  • High precision of high-speed spindle, big hole and good rigidity.

  • Using NSK bearings, maintenance-free.

  • Supersonic frequency quenching for slide guide, profile grinding.

  • The bed saddle guide coated with plastic, in low speed operating without creep.

  • No-gap motion of ball screw, keyless connection.

  • With direct drive spindle, automatic intermittent lubrication.

  • Using imported-packed bearings with high precision.

  • Armour-protected vehicle.


Application:

This lathe is designed for processing all kinds of minor axis, plate-parts. And the system provides all functions of column, cone, arc, sphere, thread, slot-cutting processing and so on. which are widely used for the processing plated-parts, sleeve parts, and minor axis parts. This machine ensures the rigidity and high surface finishes of steel/Hagane/non-ferrous metal workpiece.



Technical  Parameters:

ModelDMK50DMK50A
Max swing over bed (mm)500660
Max swing over cross slide (mm)190450
Width of bed guide rail (mm)410410
Maximum length of workpiece (mm)200300
Maximum diameter of turning (mm)500650
X-maximum travel (mm)300300
Z-maximum travel (mm)200300
Spindle head typeA2 6A2 6
The taper of spindle inner holeStraight hole / with cone diskStraight hole / with cone disk
Spindle bore diameter (mm)6565
Spindle seriesInfinitely variable speedInfinitely variable speed
Spindle speed (rpm/min)300-4000300-3500
Chuck type and size8'', 10'', collet8'', 10'', collet
Rated power of spindle (kw)7.57.5
Tailstock diameter (mm)--
Tailstock guide rail travel (mm)--
Tailstock taper hole--
Spindle unit displacement size (mm)--
X-axis rapid tranverse (mm)99
 Minimum setting unit of   X-axis (mm)0.001-
Precise of X-axis repeat orientation (mm)≤0.005≤0.005
Z-axis rapid tranverse (mm)99
 Minimum setting unit of   Z-axis (mm)0.001-
Precise of Z-axis repeat orientation (mm)≤0.005≤0.005
Rest tool type and no. of workstationMotorized tool changing/8-12Motorized tool changing/8-12
Toolbar size (mm)2525
Feeding PartsOptionalOptional
CNCOptionalOptional
Supporting Customized / Length*width*height (mm)1870*1300*16002000*1600*1650
